Alpha 149014 WS-809 Water-Soluble Solder Paste, 85-4-M10 [500g Jar]

The Alpha 149014 WS-809 is a Series WS809 water-soluble solder paste with a flash point of 185. Excellent volume transfer efficiency over broad range of environmental conditions. Fine-pitch printing with consistent shape and volume to 16 mil pitch QFP (63 x 10 x 5 mil deposits) and 15 mil circles (BGA225). High throughput and yield with consistent print volumes at print speeds ranging from 1 - 6 inches/second. Exhibits resistance to slumping and drying at temperature up to 66 - 84°F (19- 29°C) and relative humidity extremes. Water cleanable after two paste reflow cycles. Excellent low voiding performance that exceeds IPC Class III requirement. Superior solder spread performance on Cu OSP.

Alpha 149014 WS-809 Water-Soluble Solder Paste Highlights:

• Excellent volume transfer efficiency over broad range of environmental conditions
• Water cleanable after two paste reflow cycles
• Excellent low voiding performance that exceeds IPC Class III requirement
• Superior solder spread performance on Cu OSP

Alpha 149014 WS-809 Water-Soluble Solder Paste Specs:

• Brand: Alpha
• SKU: 149014
• Series: WS809
• Product Type: Water-Soluble Solder Paste
• Physical Form: Paste
• Flash Point: 185°C
• Applications: Soldering, Desoldering
• Standards Met: IPC Class III, IPC J-STD-005, IPC J-STD-004A
